1915 Series Coupling Tire Type Machinery Equipment

You can easily access comprehensive information about the dimensioning and E-Catalogue page of our products, product material contents, quality and analysis documents, certificates, assembly videos and category introductions.

Catalogue Code: 19.15
Material and Color Options (V)
19.15.A.V1 - EPDM - RAL 2010
Diameter (Ø1) Diameter (Ø2) Height (H1)
Ø57 Ø35 33 19.15.A.V1.1
Ø76 Ø44 41 19.15.A.V1.2
Ø92 Ø54 49 19.15.A.V1.3
Ø95 Ø55 47 19.15.A.V1.4
Ø111 Ø65 56 19.15.A.V1.5
Ø128 Ø73 64 19.15.A.V1.6
Ø130 Ø75 64 19.15.A.V1.7
Ø150 Ø88 75 19.15.A.V1.8
Ø180 Ø100 85 19.15.A.V1.9
Ø180 Ø102 88 19.15.A.V1.10
Technical Drawing
