18 Series Bushed Connector Lever Handles

You can easily access comprehensive information about the dimensioning and E-Catalogue page of our products, product material contents, quality and analysis documents, certificates, assembly videos and category introductions.

Catalogue Code: 1.8
Material and Color Options (V)
1.8.A.V1 - BAKELİTE - RAL 9005
Product Diameter (Ø) Bushing Metric (D) Height (H1)
Ø17 M6 40 1.8.A.V1.1
Ø17 M8 40 1.8.A.V1.2
Ø20 M6 50 1.8.A.V1.3
Ø20 M8 50 1.8.A.V1.4
Ø25 M6 73 1.8.A.V1.5
Ø25 M8 73 1.8.A.V1.6
Ø25 M10 73 1.8.A.V1.7
Ø27 M8 89 1.8.A.V1.8
Ø27 M10 89 1.8.A.V1.9
Ø27 M12 89 1.8.A.V1.10
Ø31 M8 115 1.8.A.V1.11
Ø31 M10 115 1.8.A.V1.12
Ø31 M12 115 1.8.A.V1.13
Ø31 M14 115 1.8.A.V1.14
Ø31 M16 115 1.8.A.V1.15
Technical Drawing
3D Modelling
3D Modelling

To access the product file, you can click on the "Download 3D Model" button below, fill out the form and send it.

Download 3D Model
Montage Video

To access the product file, you can click on the "Request" button below, fill out the form and send it.

Request
Technical Detail

To access the product file, you can click on the "Request" button below, fill out the form and send it.

Request
Product Raw Material Certificate

To access the product file, you can click on the "Request" button below, fill out the form and send it.

Request
Product Quality and Analysis Certificates

To access the product file, you can click on the "Request" button below, fill out the form and send it.

Request
Category Introduction

To access the product file, you can click on the "Request" button below, fill out the form and send it.

Request
