19 Series Bolted Connector Lever Handles

You can easily access comprehensive information about the dimensioning and E-Catalogue page of our products, product material contents, quality and analysis documents, certificates, assembly videos and category introductions.

Catalogue Code: 1.9
Material and Color Options (V)
1.9.A.V1 - BAKELİTE - RAL 9005
Product Diameter (Ø) Bolt Metric (D) Height (H1) Bolt Length (H)
Ø17 M6 40 15 1.9.A.V1.1
Ø17 M8 40 15 1.9.A.V1.2
Ø20 M6 50 20 1.9.A.V1.3
Ø20 M8 50 20 1.9.A.V1.4
Ø25 M6 73 20 1.9.A.V1.5
Ø25 M8 73 20 1.9.A.V1.6
Ø25 M10 73 20 1.9.A.V1.7
Ø27 M8 89 25 1.9.A.V1.8
Ø27 M10 89 25 1.9.A.V1.9
Ø27 M12 89 25 1.9.A.V1.10
Ø31 M10 115 25 1.9.A.V1.11
Ø31 M12 115 25 1.9.A.V1.12
Technical Drawing
