342 Series Bushed Connectors Knob Handles

You can easily access comprehensive information about the dimensioning and E-Catalogue page of our products, product material contents, quality and analysis documents, certificates, assembly videos and category introductions.

Catalogue Code: 3.42
Material and Color Options (V)
3.42.A.V1 - PA6 GF30 - RAL 9005
Metric (D) Length (L)
M6 46 3.42.A.V1.1
M8 46 3.42.A.V1.2
M6 60 3.42.A.V1.3
M8 60 3.42.A.V1.4
M10 60 3.42.A.V1.5
M8 74 3.42.A.V1.6
M10 74 3.42.A.V1.7
M12 74 3.42.A.V1.8
3.42.B.V1 - PPC - RAL 9005
Metric (D) Length (L)
M6 46 3.42.B.V1.1
M8 46 3.42.B.V1.2
M6 60 3.42.B.V1.3
M8 60 3.42.B.V1.4
M10 60 3.42.B.V1.5
M8 74 3.42.B.V1.6
M10 74 3.42.B.V1.7
3.42.B.V2 - PA6 GF30 - RAL 9005
Metric (D) Length (L)
M10 74 3.42.B.V2.7
M8 74 3.42.B.V2.6
M10 60 3.42.B.V2.5
M8 60 3.42.B.V2.4
M6 60 3.42.B.V2.3
M8 46 3.42.B.V2.2
M6 46 3.42.B.V2.1
Technical Drawing
